4 Inch Lift Kit | Ram 1500 (13-18) 4WD

From $6,359.95

BDS steps up the performance and capability of the 2013-2018 RAM 1500 trucks with a 4-inch suspension lift kit. Designed to improve stance, performance, and capability, this kit includes everything necessary...

Rear Lift Option: Choose an option

3 Inch Coil Springs
2 Inch Coil Spacers

Shock Option: Choose an option

FOX 2.0 Performance Series
NX2 Nitro Series
Vendor: BDS Suspension
SKU:
Availability : In Stock Pre order (We ship containers from the USA Monthly) Pre-order (6-8 Weeks from USA or Airfreight for 7-10 day delivery)

07 5500 0095 - Need help with product selection or delivery options?

BDS steps up the performance and capability of the 2013-2018 RAM 1500 trucks with a 4-inch suspension lift kit. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 35" tires

This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics. Up front, the kit utilizes top mounted strut spacers, high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection. Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles and replacement tie rod ends allowing for ESC system compatibility. These combined with the provided sway bar drops, bump stop extensions, stainless steel braided brake lines, CV spacers, supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it.

In the rear this kit utilizes a 2" coil spacer, rear upper control arm relocation brackets to correct pinion angle, track bar relocation bracket to correct axle positioning, bump stop extensions, and sway bar links. The rear of these kits are rounded out with your choice of specially tuned NX2 nitro series gas shocks or FOX 2.0 IFP performance series gas shocks to offer improved damper performance.

High Clearance Crossmembers

BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.

Heavy Duty Steering Knuckles

BDS corrects steering geometry at the new taller ride height using a pair of high-strength, CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.

  1. The Rack and Pinion steering system is extremely sensitive to an out-of-round or out-of-balance tire/wheel combination. As you increase the tire diameter and/or decrease the wheel backspacing the more sensitive the system becomes and can cause minor steering wheel shimmy.
  2. Not recommended for AWD models.
  3. Stock 17" and 18" wheels can not be re-installed. Stock 20" can be reinstalled with a factory tire.
  4. Will not fit adjustable air suspension equipped models.
  5. This kit will bolt on Eco-Diesel models but it will require an aftermarket front drive shaft.
  6. This kit is FMVSS No.126 Compliant.

Download Guide 1 Download Guide 1

Download Guide 2 Download Guide 2

  • Front Lift Method : Cross-Member
  • Front Lift Height : 4"
  • Rear Lift Method : Coil Spring
  • Rear Lift Height : 3"
  • Shocks Included : Yes
  • Lift Height : 4-5.5"
